Product Details:
Place of Origin: Chengdu, Sichuan
Brand Name: TNW
Certification: ISO 9001, ISO 14001,CMA
Model Number: TNWPE-2000
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiatable
Packaging Details: Wooden box
Delivery Time: 3-7 weeks
Payment Terms: T/T, L/C
Supply Ability: 10 Sets per month

Water Treatment Plant Automatic Chlorine Dosing System For Drinking Water

Description
Product Name: Chemical Dosing System Water Treatment Material: PE
Volume: 80L 100L 200L 300L 500L 1000L 1500L 2000L 3000L 5000L Application: Chilled Water, Cooling Water,air Conditioning System,boiler
Power: 2kW Key Words: Dosing System
Function: Corrosion, Scale Inhibition, Sterilization And Algae Remova Pressure Range: 0.2-1Mpa
PH Meter: Optional After Warranty Service: Video Technical Support
High Light:

automatic chlorine dosing system

,

chlorine dosing system in water treatment plant

,

chlorine dosing system for drinking water

Sludge Dewatering Machine



Automatic Chlorine Dosing System Chemical Mixing Machine With Dosing Pump For Wastewater Treatment



Water Treatment Plant Automatic Chlorine Dosing System For Drinking Water 0



Specification


With the dosing units you can easily and reliably condition the water to serve the intended use and to meet the technical requirements. The field of applications includes the dosing of:


* Acids for alkalinity reduction and scale prevention


* Polyelctrolytes for coagulation of suspended solids and an improved subsequent filtration


* Scale inhibitors to avoid scale deposits on reverse osmosis membranes


* Disinfectants for shock treatment in order to avoid bacterial growth


* Chlorine to avoid biological growth in pipes and storage tanks


* Hydrated lime or caustic soda for pH adjustment to neutralize dissolved free carbon dioxide.


Features:

* high dosing accuracy.

* local control for adjustment of dosing rate.

* integral dosing head deaeration.

* for degasing of chemicals.

* easy installation and maintance.

* high operational reliability.

* high quality materials.

* accessories in great variety.

(All customized models are available by online inquiry).


Yellow/White tank : Solution Tank

Materail : PE Material

Volume: 80L 100L 200L 300L 500L 1000L 1500L 2000L 3000L 5000L

Top of the dosing tank : Mixer ( Agitator) :
Rated Power : 0.37- 1.5KW ( normally used )
Mixing Speed : 130rpm/min

The cage install the Metering Pump :

- Mechanical Actuated disphragm , no- leadkage structure
- Pump material : PVC ,PTFE , PVDF , 304,316 , all of them are avaiable as the Pump head material
- Flow can be adjusted during operation , the range is 0.5-500L /H

Pressure Range : 0.2-1Mpa
- Automatic control who can accpet 4-220MA is avaiable
-Motor : standrad 220V / 380V , 50HZ

  • Product Graphic Details



Water Treatment Plant Automatic Chlorine Dosing System For Drinking Water 1
