ISO 14001 1500L Automatic Dosing System Sludge Dewatering Equipment

Sludge Dewatering Machine

1500l PE Material Tank Dosing Automatic System For Water Plant And Sludge Treatment

Main components of the 1500l PE Material Tank Dosing Automatic System

Stirring device, liquid storage tank, metering pump, pipe filter, PH meter and other main components.

Working Principle

The dozing system is mainly composed of solution tank, mixing tank (with stirrer), metering pump, level gauge, electric control cabinet, pipeline, valve, safety valve, check valve, pressure gauge, filter, base, escalator, etc. (can be configured according to the actual requirements of users). Dosing system according to the required concentration of the drug, in the mixing box preparation, after stirring evenly into the solution box, with a metering pump (dosing pump) to the dosing point or the designated system delivery of the prepared solution.

Equipment Characteristics

1, intensive design, small footprint, simple structure, stable performance

2, accurate measurement, convenient adjustment, good economy, easy to install

3, pump for suction installation, not easy to plug, long trouble-free running time, low operating cost

4, excellent corrosion resistance, long service life

5. It can be used as the speed control system of AC motor such as water pump, oil pump and fan to realize the pressure and flow control of liquid and vapor body in the infusion pipeline.

6, solution box material: PE, glass fiber reinforced plastic, carbon steel lining, 304 stainless steel, 316 stainless steel

7, blender material: 304 stainless steel, 316 stainless steel

8, metering pump flow part of the material: PP, PVC, PVDF, SS316

Range Of Application

1, boiler injection of chemical agents, mainly used in dynamic power plant, chemical industry, metallurgy, ships, central heating and other practical boiler occasions

2. It is used for pretreatment and dosing of tap water supply. It is mainly used in urban waterworks, large enterprises' own waterworks, textile printing and dyeing, iron and steel, paper making and other industries

3, environmental protection in the waste water, sewage treatment in the dosing, mainly used in the city, industrial and mining enterprises, large hotels, restaurants waste water sewage treatment

4. Liquid dosing system for other related industries

Maintenance of dosing device

1. The pipeline of the dosing device should be kept unblocked at any time. Check the connection parts, filters, feeding ports and discharging ports of the device from time to time to observe whether there are deposited substances in these parts.

2. Regularly check whether the feed port of the metering pump is blocked, and clean the pipeline and filter regularly to prevent blockage.

3. Regularly check the stirring device to check whether the stirring shaft is flexible, whether the impeller is twisted and deformed, and whether the coupling sleeve is loose, so as to avoid excessive torque of the shaft and consumption of stirring power. If there is damage, it should be replaced in time.

4. Check the safety valve, pressure gauge and pipeline valve regularly to avoid leakage.

• Product Graphic Details

Company Profile

Chengdu Yuanjin Environmental Protection Engineering Co., Ltd. was established in 2012 . The company is a high-tech enterprise. It has obtained a number of certificates such as a patent certificate, nine software copyrights, a construction enterprise qualification certificate, and ISO9001 international quality management system certification.
