Product Details:
|
| Product Name: | Waste Water Treatment Machine | Material: | Carbon Steel |
|---|---|---|---|
| Application: | Waste Water Treatment | Capacity: | 10-5000 M3/d |
| Color: | White /Bule/Customized | Origin: | China |
| Control Mode: | Automatic | Power: | Customized |
| Processing Capacity: | Customized | Treatment Effect: | High |
| High Light: | 50m3/D Sewage Treatment Equipment,Carbon Steel Sewage Treatment Equipment,Customized Wastewater Treatment Machine |
||
Integrated Sewage Treatment Equipment
50m3/d Energy-Saving Integrated Sewage Treatment Equipment
Product introduction
The CD · Jin integrated sewage treatment reactor developed by our company is an efficient, energy-saving, and economical new generation integrated sewage treatment reactor mainly used for domestic sewage, hospital sewage, and industrial sewage treatment
Process flow
The sewage first passes through the sewage collection pipe to the septic tank for pre-treatment, and then enters the grid tank to intercept large garbage and suspended matter, and remove floating and large particle suspended impurities in the sewage; Then it enters the regulating tank. Under the action of the regulating tank, after the water quality and quantity are balanced, the sewage is pumped into the CD·JIN sewage comprehensive treatment reactor through the lifting pump.
The functional area of the integrated reactor for sewage treatment is a longitudinal ring structure. The sewage enters the primary zone through the lifting pump, and is effectively contacted through the water distribution system. After the treatment in the primary zone, the sewage rises into the secondary zone of the outer ring, which is equipped with a ring aeration biochemical system. The sludge and water are separated by a combination of physics and chemistry. The sludge in the third-level zone is continuously circulated to the first-level zone. Meanwhile, the flow rate control diffuser in the third-level zone can return part of the sewage to the first-level zone, and part of the sludge and water are separated. CD·Jin uses the three-way flow of upward flow in the outer ring, gravity flow in the inner ring and horizontal circulation, which can produce full mixing effect and ensure microbial activity. After the water is discharged from the third level area, it enters the main engine for further treatment. The main engine is equipped with contact disinfection area, equipment room and automatic control system, which is convenient for equipment maintenance and emergency treatment.
Specification and model
