50m3/H PLC Tunnel Sewage Treatment Plant Machine Systems Tubular Membrane

Industrial Wastewater Treatment Equipment

50m3/H PLC Tunnel Sewage Wastewater Treatment Equipment Tubular Membrane

 Equipment Description

The Industrial Wastewater Treatment Equipment is a comprehensive equipment to treat all kinds of sewage. The process goal of the equipment is to discharge all kinds of sewage after treatment to meet the discharge standard. The equipment has strong impact load resistance. With nitrogen removal, phosphorus removal function, and by regulating the structure of the equipment, to achieve the capacity of sewage treatment; The equipment can be located above ground or buried underground. Buried in the ground, the upper can be used for greening, less floor space, less ground structures, easy to complete automatic control, and has the characteristics of convenient installation, simple operation, convenient maintenance, long service life.

Working Principle
Industrial Wastewater Treatment Equipment series products adopt A2O+ tubular membrane technology. In the A2O process, nitrification, denitrification and biological phosphorus removal are completed based on activated sludge microorganisms. In the tubular membrane process, the feed liquid flows through the inner surface of the membrane tube under pressure, and the trapped material (suspended solid particles) is carried out of the membrane tube by the concentrated liquid, thereby preventing the particulate matter from accumulating into a cake.
Influent and effluent quality indicators



Device parameters





Equipment Advantages


1. high efficiency, can effectively separate liquid, suspended matter, colloidal substances and microorganisms. The treated water can be discharged directly without further treatment.

2. The biomass in the biological treatment unit can be kept at a high concentration, which greatly increases the volume load. At the same time, the high efficiency of membrane separation can greatly shorten the hydraulic retention time of the treatment unit, and the footprint of the bioreactor is also reduced accordingly.

3. Because it can prevent the loss of various microbial flora, it is conducive to the growth of bacteria with slower growth rate (nitrifying bacteria, etc.), so that various metabolic processes of the system can proceed smoothly.

4. The residence time of some macromolecular refractory organic matter is prolonged, which is conducive to their decomposition.

5. The membrane treatment technology is the same as other filtration and separation technologies. When running for a long time, the membrane is contaminated and the membrane is blocked as a filter medium. The water flow rate of the membrane decreases gradually during operation. Effective backwashing and chemical cleaning can slow membrane flux. Reduce to maintain the effective service life of the membrane system.

6. a wide range of application, strong operability, without manual supervision.

Process Characteristics
1. The equipment has patented biological filting;
2. Strong ability to treat sewage;
3. No aeration, environmental protection and energy saving;
4. Easy to store, high pressure resistance, aging resistance;
5. No membrane tank, no sludge thickening tank, unit type vertical arrangement, saving land.

Product Details



Water Purification Comparison




Mature Technology Scientific Structure


Tubular membranes are not self-supporting membranes. They are located on the inside of a tube, made of a special kind of material. This material is the supporting layer for the membrane. Because the location of tubular membranes is inside a tube, the flow in a tubular membrane is usually inside out. The main cause for this is that the attachment of the membrane to the supporting layer is very weak.
Tubular membranes have a diameter of about 5 to 15 mm. Because of the size of the membrane surface, plugging of tubular membranes is not likely to occur. A drawback of tubular membranes is that the packing density is low, which results in high prises per module.


Application
Industrial Wastewater Treatment Equipment is suitable for the residential area, villages, towns and villages, office buildings, shopping malls, hotels, restaurants, nursing homes, organs, schools, units, hospitals, highways, railways, factories, mines, scenic spots such as sewage and similar slaughter, aquatic products processing, food and other small and medium size industrial organic wastewater treatment and reuse.




Real  Shot  Display



Company Real Show



Chengdu Yuanjin Environmental Protection Engineering Co., Ltd. was established in 2012 with a registered capital of 20 million. The production workshop covers an area of 1,400 square meters. There are more than 20 employees, including 2 senior engineers, 4 intermediate engineers, and 14 professional technicians; our company's technical team, all It is composed of a group of people who have worked in the field of water treatment for a long time. The company is a high-tech enterprise. It has obtained a number of certificates such as a patent certificate, nine software copyrights, a construction enterprise qualification certificate, and ISO9001 international quality management system certification. The environmental protection project will strive to build the most well-known Chengdu water treatment company. We have always adhered to the tenet of "quality first, customer first" and the management policy of "integrity, pragmatism, responsibility and efficiency", and advocated new ideas and new technologies. Tolerance for failure is the company's philosophy, which ensures that every employee of our company can pay for the company wholeheartedly, and that every one of our customers is satisfied with the services provided by the company.

FAQ

1. Why choose us?
1) Yuanjin has 12 years of experience in wastewater and sludge treatment.
2) We introduce advanced technology and experience at home and abroad, and have been committed to the research and development of water treatment equipment for a long time.
3) We only use the best parts from the best suppliers.
​4) Yuanjin's technical team is composed of a group of people with long-term working experience in the field of water treatment to provide customers with high-quality services.

2. What is the price of the product?
According to the amount of water treated, the price is different, and the unit price range is 145~866 $/m3·d.
3. What is the effect of the treated water?
1) The treated pure water can be directly consumed and meets the World Health Organization (WHO) drinking water quality standards.
2) The sewage can be directly discharged after treatment, which is environmentally friendly and meets the requirements of international sewage treatment discharge standards.
